Single-Axis Medium-High Precision FOG

Payment Terms : T/T

Electricity : RS422

Model Number : LKF-FS70

Measure Azimuth Angle : ±180 deg

MOQ : 1

Delivery Time : 2-4 weeks

Zero Drift Stability : ≤0.20 °/hr (1σ, 10s)

Manufacturing Date Code : 2023

Packaging Details : Wooden box/Cardboard box/Container

Price : 5000-25000CHY

Output : RS422 bps115200~921600

Supply Ability : 10000

Storage Temperature : 25℃ ~±10℃

Certification : GJB 9001C-2017

Technology : Fiber Optic Gyroscope

Brand Name : Liocrebif

Settling Time : 10s

Place of Origin : China

Speed Accuracy : 0.01m/s

Contact Now

Product Overview

The LKF-FS70ZK is a miniaturized fiber optic gyroscope with integrated circuitry and optical paths that break from traditional designs. It serves as an ideal high-precision angular rate sensor for control applications and is widely used in inertial measurement. Built on proven designs with engineering optimizations for mass production, it delivers exceptional cost performance. Featuring compact size, light weight, low power consumption, and a simple interface, the LKF-FS70ZK is the top choice for navigation and control fields.

Main Features

  • Miniature Compact Design
  • All-Solid-State Design
  • Strong Environmental Adaptability
  • High Reliability, Ultra-Long Lifetime
  • Fully Digital RS-422 Electrical Interface Output

Application Fields

  • EO Pod
  • Flight Control Platform
  • Optical/Photography Platform
  • Platform Stabilization Device
  • SatCom-on-the-Move
  • Inertial Measurement Unit
  • Lightweight UAV

LKF-FS70ZK Single-Axis FOG Performance Parameters

Parameter A B Remarks
Bias Stability (°/hr ,1σ, 10s) ≤0.05 ≤0.03 2h Continuous Test, 10s avg. Result
Bias Repeatability (°/hr ,1σ) ≤0.05 ≤0.03 Calculated Results from 6 Test Runs
Angle Random Walk (ARW) (°/√h) ≤0.005 ≤0.003
Scale Factor Nonlinearity (ppm ,1σ) ≤10 ≤10 Room Temperature
Scale Factor Repeatability (ppm ,1σ) ≤20 ≤10 Room Temperature
Full-Temp. Scale Factor Repeatability (ppm ,1σ) ≤300 ≤200 -40℃～+60℃
Dynamic Range (°/s) ±500
Magnetic Sensitivity (°/hr/Gs) ≤0.02
Operating Temperature (℃) -40～+70
Storage Temperature (℃) -50～+70
Vibration Condition (g, Hz) 4.2,20～2000 No resonance in the scanning
Weight (g) 280±30
Dimensions (mm) 70*70*30
Note: This series of gyroscopes features hermetic sealing.
